目的 建立黄芪注射液中亲水性成分和疏水性成分的1H-NMR定量分析方法。方法 以10%氘代水(10% D2O)和氘代甲醇(CD3OD)为氘代溶剂制备黄芪注射液亲水性成分和疏水性成分的1H-NMR样品。使用Bruker Avance III 600型核磁共振波谱仪采集1H-NMR图谱,具体实验参数如下:Noesygppr1D脉冲序列;温度为298 K,数据点32 K,采集时间(AQ)为2.980 s,脉冲宽度(SW)为7 211.54 Hz,弛豫延迟时间(D1)分别为15.0 s和20.0 s,频率偏移(O1)分别为2 816.65 Hz和2 930.31 Hz,接收器增益(RG)值为57,扫描次数(NS)32次。结果 在1H-NMR图谱中归属出33种成分,分别是异亮氨酸、亮氨酸、缬氨酸、丙氨酸、乳酸、焦谷氨酸、天冬酰胺、γ-氨基丁酸、脯氨酸、甲酸、乙酸、富马酸、苹果酸、琥珀酸、丙二酸、蔗糖、果糖、半乳糖、葡萄糖、胆碱、甜菜碱、葫芦巴碱、尿苷、腺苷、胞苷、鸟苷、腺嘌呤、黄芪皂苷III、黄芪甲苷、芒柄花苷、毛蕊异黄酮苷、9,10-二甲氧基紫檀烷-3-O-葡萄糖苷以及异黄烷苷。对其中27种化学成分(异亮氨酸、缬氨酸、丙氨酸、乳酸、焦谷氨酸、天冬酰胺、γ-氨基丁酸、脯氨酸、甲酸、乙酸、富马酸、苹果酸、琥珀酸、丙二酸、蔗糖、果糖、葡萄糖、胆碱、甜菜碱、葫芦巴碱、尿苷、腺苷、鸟苷、腺嘌呤、黄芪皂苷III、黄芪甲苷、毛蕊异黄酮苷)进行定量,可定量的成分占注射液固含量90%以上。该方法的精密度、重复性、样品稳定性和耐用性良好,各个成分线性关系良好,r2大于0.999 0,加样回收回收率为98.19%~101.40%。结论 建立了一种简单、快速、可靠的1H-NMR定量方法用于测定黄芪注射液中的亲水性成分和疏水性成分,为黄芪注射液的质量评价提供了新的分析手段。
[Key word]
[Abstract]
Objective To establish a 1H-NMR quantitative method for the hydrophilic and hydrophobic components in Astragalus Injection (黄芪注射液). Methods 1H-NMR samples of hydrophilic and hydrophobic components in Astragalus Injection were prepared with 10% deuterated water (10% D2O) and deuterated methanol (CD3OD), respectively. Then Bruker Avance III 600 NMR spectrometer was used to collect 1H-NMR spectra. The parameters were set up as follows: Noesygppr1D pulse sequence, temperature was 298 K, data point was 32 K, acquisition time (AQ) was 2.980 s, pulse width (SW) was 7 211.54 Hz, relaxation delay time (D1) was 15.0 s and 20.0 s, respectively, frequency offset (O1) were 2 816.65 Hz and 2 930.31 Hz, respectively, receiver gain (RG) was 57, and the number of scans (NS) was 32. Results A total of 33 components were assigned, namely isoleucine, leucine, valine, alanine, lactate, pyroglutamate, asparagine, γ-aminobutyric acid, proline, formate, acetate, fumaric acid, malic acid, succinic acid, malonic acid, sucrose, fructose, lactose, glucose, choline, betaine, trigonelline, uridine, adenosine, cytidine, guanosine, adenine, astragaloside III, astragaloside IV, ononin, calycosin-7-glucoside, 9,10-dimethoxypterocarpan-3-O-glucoside and isomucronulatol 7-O-glucoside. Quantitative analysis was conducted for 27 chemical constituents, including isoleucine, valine, alanine, lactate, pyroglutamate, asparagine, γ-aminobutyric acid, proline, formate, acetate, fumaric acid, malic acid, succinic acid, malonic acid, sucrose, fructose, glucose, choline, betaine, trigonelline, uridine, adenosine, guanosine, adenine, astragaloside III, astragaloside IV and calycosin-7-glucoside. The components that can be quantified by this method account for more than 90% of the solid content in the injection. The methodological validation results showed that the method’s precision, repeatability, sample stability, and robustness were good. The linear of each component was good, the correlation coefficient was more than 0.999 0, and the recovery rate ranged from 98.19% to 101.40%. Conclusion A simple, rapid and reliable 1H-NMR quantitative method was established to determine hydrophilic and hydrophobic components in Astragalus Injection, which provided a new analytical method for the quality evaluation of Astragalus Injection.
[中图分类号]
R283.6
